Epoxy- mica paper-glass cloth-combination thermosetting
Composition
Calmicaglass N(I)™ consists of mica paper based on uncalcined muscovite, glass cloth and thermosetting epoxy novolak.
Calmicaglass N(I)™ is supplied interleaved to prevent a sticking together of the layers.
Calmicaglass N(I)™ is a very flexible glass mica paper combination, which can be taped easily on tight bends.
Calmicaglass N(I)™ when pressed gives a good resin flow that ensures the insulation of complex shapes. Excellent dielectric, thermal, mechanical and chemical properties are obtained after pressing.
Calmicaglass N(I)™ is used e.g. for the insulation of coils and bars of low and high voltage machines.
Moreover, C Calmicaglass N(I)™ can be used for the fabrication of moulded parts such as commutator caps or for the fabrication of wound tubes and cylinders.
Min. 6 months at 20°C
Max. 12 months at 5°C
Rolls: max. width 1000 mm
Tapes: from 10 mm width upwards
